Aqara 2 Way Relay Module

1.Document Purpose Standardize the wiring operations of the power supply part of Wireless Relay Controller (2 Channels) 2.Applicable Product Wireless Relay Controller (2 Channels) 3.Scope of Application Operations of client side Operations of client side 4.Preparation Prepare items and environment: one Aqara Wireless Relay Controller (2 Channels) , one power cord, and one Phillips screwdriver. 5.Wiring Operation Process 5.1Jumper Wiring Note: Connect one end of the red jumper wire to L and the other end to IN. The screws must be tightened. After tightening them, you can try pulling the cable to check whether it is fixed. Remarks: The other end of the jumper wire can connect to one of the two IN ports, except for the connection method shown in the above picture. 5.2Power Code Wiring
